W650F – lattice tower
Product cards:
The 650F tower is assembled from 3 meter sections. Each segment is in the shape of a triangle with a side length of 650mm, which are connected by a flange. The tower stands in a vertical position thanks to the use of galvanized stays, there is no rope guys.
Construction: triangle truss with a side 1000mm (first segment of the tower) to 650mm (top of the tower)
Segment Lenght/Weight: 6m: ~ 32[kg] 3m: ~ 15[kg].
Segment: bolted flangesMaterial: aluminium EN AW-6005A T6
Welding:TIG
[PDF] LIST OF CONSTRUCTION EQUIPMENT W650F
All structure fitting have certificates and atest that comply with European Council Directives and national legislation.
Accessories for W650F
Aerial bracket WA650F
Warranty: 24 months.
Aerial bracket WR650F
WR650F is a radio link support, which can be optionally mounted to the tower structure of the M650F line, on which you can mount devices to fi60 or fi50 pipes up to a length of 1 m. The set includes clamps for mounting on any height. The installation of transceivers increases safety on tower.
Tower final WR650F Coping with a spacing crown
Coping with a spacing crown with distance of 400mm, can be installed to pipes fi50 or fi60. Increases safety.
Tower final coping with spacing WR650F
Warranty: 24 months
